■ SPECIFICATIONS
|
|
|
Component part
|
Material
|
Standard
|
Plated
|
Remark
|
|
Base
|
Nylon-66
|
UL94V-0
|
|
Natural(백색으로보임)
|
|
Terminal
|
Brass
|
1/2H
|
Nickel
|
1.2t
|
|
Screw
|
Steel
|
|
Nickel
|
M5
|
|
Wire protector
|
Stainless Steel
|
STS 304
|
|
0.3t
|
|
|
|
|
Current rating
|
250V 40Amp
|
|
Insulation resistance
|
1000M Ohms of More at DC500V
|
|
Withstand voltage
|
AC 2000V / Minute
|
|
Wire range
|
AWG #10 ~ #20(SOL)
|
|
Torque
|
18.0 lb-in
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PCB Terminal blocks
